Front-loading tray trolleys

Capacity
single type 16-20 pans
double type 32-40 pans

for trays 400x600

Technical Characteristics

• AISI 304 stainless steel construction
• Supporting structure and base made of AISI 304 stainless steel, section 40x40
• Tray rails made of round tube Ø 16
• Push handle made of round tube Ø 16
• Non-marking pivoting wheels made of synthetic rubber with chromed support, Ø 80x22, two with brake (optional with inox support)
• Supplied completely welded

Models front loading tray trolleys:

Capacity 16 Trays 400 x 600 20 Trays 400 x 600 Models CTF16 CTF20 Code 807305 807310 Length mm 500 500 Depth mm 540 540 Height mm 1790 1790

Capacity 32 Trays 400 x 600 40 Trays 400 x 600 Models CTF32 CTF40 Code 807315 807320 Length mm 500 500 Depth mm 960 960 Height mm 1790 1790
